Product Description
C1C
- Compatible ATC products for surround sound system: SCM 7, SCM 11.
- New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.
- Twin 125mm ATC mid/bass unit with integral soft dome.
- Massive FEA optimised motor assemblies.
- In-house, hand wound precision flat wire coils.
- Flat impedance curve allowing easy load for amplifiers.
- 6 year warranty.
Drivers: HF ATC 25mm Neodymium, Mid/LF 125mm
Matched Response: +/- 0.5dB
Frequency Response (-6dB): 57Hz–22kHz
Sensitivity: 86dB @ 1W @ 1metre
Max SPL: 103dB
Nominal Impedance: 8 Ohm
Recommended Power Amplifier: 75 to 300 Watts
Crossover Frequency: 2.5kHz
Cabinet Dimensions (HxWxD): 161x410x280mm (grill adds 28mm depth)
Weight: 12kg
Recommended Configuration
| Front Channels / Rear Surround | SCM7 |
| Centre Channel | CIC |
| Sub Bass | C1 Sub |
| Upgrade Path | SCM11 (Front/Rear left/right) C4 Sub |
