Product Description
Step up from the NAC 202 and you arrive at the outstanding NAC 282, which includes the NAPSC power supply unit optionally available on its sibling. The NAPSC independently powers the NAC 282’s digital and control circuits, leaving its audio circuits to either the power supply of a NAC 155 XS or NAP 200 power amplifier, or to one of Naim’s standalone FlatCap XS, HiCap or SuperCap power supplies. The result is even greater transparency and superior musicality plus, of course, all the flexibility you’d expect from one of Naim’s preamplifiers.
Features
- Support for both DIN and RCA inputs to facilitate connection into a wider range of systems
- Silent microprocessor control that sleeps during listening
- Precision rotary potentiometers with precious metal wipers
- AV bypass mode for simple connection to an existing AV system
- Powered input for use with StageLine or SuperLine phono stages
Performance upgradable with FlatCap XS, HiCap or SuperCap power supply; can also be powered from the preamp inputs of the NAP 155 XS or NAP 200 power amplifier
| Analogue Input | 4 x DIN, 2 x DIN, RCA |
| Input Sensitivity | 75mV |
| Input Impedance | 47kΩ |
| Other Inputs | AV input configurable for unity gain |
| Audio Outputs | 2 x variable (DIN), 3 x fixed (DIN) |
| Line Outputs Fixed (level) | 75mV, 600Ω |
| Line Outputs Variable (level) | 775mV |
| Other Outputs | <50Ω |
| Load Impedance | 10kΩ (min.) |
| Power Outputs | Naim phono amplifier |
| Remote Control | Infra Red (RC5) |
| Remote Input | RCA on rear (RC5) |
| RS232 | Optional (DE9 female) |
| Front Panel | Volume control, balance control, sixteen button matrix |
| Handheld | NARCOM-4 Remote Control |
| Supply Voltage | 18V, 24V |
| Power Supply Options | NAP 155 XS, NAP 200, FlatCap XS, HiCap, SuperCap |
| Power Supply | 2 x Hi-Cap/SuperCap |
| Other | NAPSC |
| Dimensions (HxWxD) | 87 x 432 x 314 mm |
| Weight | 7.0 kg |
| Supplied with | NARCOM-4 Remote Control |
| Front | Brushed and black anodised |
| Case | Black powder coated |
