Product Description
There is an unwritten rule in high-end audio that states audiophile performance levels can only be achieved through separates. By combining technologies pioneered by reference products such as the NDX and SUPERNAIT 2 and adding a few innovations of its own, the SuperUniti demonstrates just how far our research has taken us with all-in-one sound quality. It’s proof that sometimes, rules are made to be broken.
SuperUniti is an integrated wireless UPnP network stream player, USB audio player, iPod dock, internet radio, DAB/FM radio, ten input digital and analogue preamplifier, digital to analogue converter and stereo 80W power amplifier. And it even includes Bluetooth (aptX) connectivity, native support for TIDAL high fidelity music streaming service and built-in support for Spotify Connect. SuperUniti forgoes the CD player offered by the NaimUniti 2 to put all of its efforts into being the best network streaming all-in-one it can be – focus you’ll hear in every note, riff and chorus.
Features
- UPnP-enabled to allow streaming of audio files at up to 24bit/192kHz resolution from Naim Audio hard disk servers, network-attached storage (NAS) devices or any home computer
- Integrated 80W per channel amplifier shares design DNA with iconic NAIT integrated amp
- Supports a broad range of music formats: WAV, FLAC, DSD (single rate), Apple Lossless, AIFF, AAC, Windows Media-formatted files, Ogg Vorbis and MP3
- Six 24bit/192kHz-capable digital inputs (S/PDIF) to support optimum connection to external sources
- Spotify Connect built-in to stream millions of songs from the world’s most popular streaming service
- Native support for TIDAL streaming service with free 90 day trial of lossless HiFi tier
- Bluetooth connectivity with aptX codec for quality audio playback
- DAB+/DAB/FM radio module as standard
- vTuner 5* full-service internet radio
- Multiroom & Party Mode compatible
- iOS and Android Naim Audio app for intuitive control
Technology & Craft
Crowding so much audio technology in one place brings numerous challenges of component selection, circuit and component layout, power supply noise and microphony. Meeting such challenges however is second nature at Naim Audio and the expertise that brings solutions has long been part of the audio engineering culture. SuperUniti is a masterpiece of audio technology packaging.
The SuperUniti amplifier is derived from our reference integrated the SUPERNAIT 2. Its digital hardware is drawn from the NDX network player and its 24bit/192kHz capable DAC uses the same data-buffering jitter removal process as the Naim Audio DAC. Along with drawing from the best existing Naim Audio technologies, SuperUniti introduces a new technology of its own. Behind the traditional looking volume dial lies an advanced new control technology providing noise-free digital volume adjustment that varies its operating characteristic depending on how quickly the volume knob is turned. All this innovation offers you the simplicity of a one box solution with the performance the Naim Audio badge guarantees.
Specifications
| Digital (S/PDIF) | 6 x S/PDIF: – 1 x coaxial BNC – up to 24bits/192kHz – 1 x coaxial RCA – up to 24bits/192kHz – 3 x optical TOSlink – up to 24bits/96kHz – 1 x front panel mini-TOSLINK – up to 24/96kHz |
| Analogue | 2 x RCA, 1 x front panel 3.5mm jack (combined optical), 1 x DIN |
| USB | 1 x front panel Type A socket (also used for iPod) |
| Input Sensitivity | 270mV at 47kΩ |
| UPnP | Wi-Fi (802.11 g or n at 2.4GHz), F type (plus PAL adapter) |
| Antenna | 802.11 b/g at 2.4GHz |
| Other | Spotify Connect, Bluetooth (SBC, AAC and aptX Classic, aptX Low Latency) |
| Digital (S/PDIF) | 1 x BNC (75Ω) |
| Analogue | Speaker output, preamp output (RCA) |
| Power Output | 80W per channel into 8Ω, 120W per channel into 4Ω (0.1% THD both channel driven) |
| Frequency Response | 10Hz-20kHz, +0.1/-0.5dB |
| Signal-to-Noise Ratio | 85dB A-WTD ref 1W 8 Ω |
| Output Impedance | 22Ω |
| Load Impedance | 10kΩ min |
| Sub Output | 1 x RCA pair |
| Headphone Output | 1 x 3.5mm jack |
| Remote Control | Infra Red (RC5) |
| Remote Input | 3.5mm jack on rear (RC5) |
| Remote Output | 3.5mm jack on rear (RC5) |
| Updates | 1 x USB Type Mini-B |
| Audio Formats | WAV (up to 24bit/192kHz) AIFF (up to 24bit/192kHz) FLAC (up to 24bit/192kHz) DSD (single rate DSF64 & DFF64 only) ALAC (up to 24bit/96kHz) WMA (up to 16bit/48kHz) must be WMA 9.2 Ogg Vorbis (up to 16bit/48kHz) M4a (CBR and VBR up to 320kbit/s) MP3 (CBR and VBR up to 320kbit/s) Playlists (M3U, PLS) |
| Internet Radio Provider | vTuner 5* full service |
| Internet Radio Formats | Windows Media-formatted content, MP3, ACC, Ogg Vorbis streams and MMS |
| Multiroom | Master: Will stream WAV, FLAC and AIFF (up to 24bit/48kHz), ALAC (up to 16bit/44.1kHz), AAC and MP3 (up to 16bit/48kHz) files only as MP3 320kbps quality. |
| DAB Tuning Range | Band III and L Band, F Type |
| FM Tuning Range | 87.5 – 108MHz, F Type |
| Front Panel | Volume control, logo touch-sensitive mute function and nine button matrix |
| Handheld | Remote handset included and optional Naim app for iOS and Android. |
| Supply Voltage | 100V, 115V, 230V; 50 or 60Hz |
| Power Consumption | 400VA (max) |
| Amplification | External power amplifier |
| Other | Power-Line, Hi-Line, WA5 antenna |
| Dimensions (HxWxD) | 87 x 432 x 314 mm |
| Weight | 12.8 kg |
| Supplied with | Uniti Remote Control |
